TDK Charging Coils:
Atrasti 22 produktiAtrodiet milzīgu TDK Charging Coils klāstu veikalā Farnell Latvija. Mūsu rīcībā ir plašs Charging Coils klāsts, piemēram, WR Series, WT Series, WR-NFC Series & WCT Series no Tdk
Skatīt
Pircējs
Inženieris
Ražotājs
Product Range
Inductance
Inductance Tolerance
DC Resistance Max
No. of Coils
No. of Layers
Product Length
Product Width
Product Height
Inductor Mounting
Operating Temperature Min
Operating Temperature Max
Iepakojums
Piemērotais(-ie) filtrs(-i)
1 Atlasīts(-ie) filtrs(-i)
| Salīdzināt | Cena par | Daudzums | |||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Each | 1+ 1,540 € 50+ 1,170 € 100+ 1,110 € 250+ 0,966 € 500+ 0,929 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 12.8µH | - | 1.27ohm | 1 Coil | 2 Layers | 10mm | 30mm | 0.52mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 4,330 € 10+ 4,310 € 25+ 3,200 € 50+ 3,130 € 100+ 3,050 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 19µH | - | 0.7ohm | 1 Coil | 1 Layer | 44mm | 40mm | 0.62mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 4,990 € 5+ 4,520 € 10+ 4,040 € 25+ 3,580 € 50+ 3,380 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 13µH | - | 0.2ohm | 1 Coil | 1 Layer | 32.5mm | 48.5mm | 1mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 3,750 € 10+ 3,260 € 25+ 2,830 € 50+ 2,520 € 100+ 2,440 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 12.3µH | - | 0.41ohm | 1 Coil | 1 Layer | 30mm | 30.4mm | 0.92mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 2,950 € 10+ 2,430 € 50+ 2,250 € 200+ 1,960 € 400+ 1,890 € Citas cenas... | Min.: 1 / Vair.: 1 | WT Series | 6.8µH | ± 5% | 0.18ohm | 1 Coil | 2 Layers | - | - | 2.42mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 2,500 € 50+ 1,790 € 100+ 1,640 € 250+ 1,490 € 500+ 1,420 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 8.32µH | ± 5% | 0.98ohm | 1 Coil | 1 Layer | - | - | 0.34mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 6,200 € 50+ 5,480 € 100+ 4,750 € 250+ 4,400 € 500+ 4,210 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 16.7µH | - | 0.65ohm | 1 Coil | 1 Layer | 44mm | 40mm | 0.52mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 2,590 € 50+ 1,860 € 100+ 1,610 € 250+ 1,570 € 500+ 1,530 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 27µH | - | 1.1ohm | 1 Coil | 2 Layers | - | - | 0.87mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 2,690 € 10+ 2,210 € 50+ 1,940 € 100+ 1,930 € 200+ 1,920 € Citas cenas... | Min.: 1 / Vair.: 1 | WT Series | 6.2µH | ± 5% | 0.095ohm | 1 Coil | 2 Layers | - | - | 2.84mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 3,850 € 10+ 3,330 € 50+ 3,100 € 100+ 2,950 € 200+ 2,890 € Citas cenas... | Min.: 1 / Vair.: 1 | WT Series | 6.3µH | ± 5% | 0.115ohm | 1 Coil | 2 Layers | - | - | 2.15mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 7,340 € 5+ 6,520 € 10+ 5,690 € 25+ 5,300 € 50+ 4,900 € Citas cenas... | Min.: 1 / Vair.: 1 | WT Series | 24µH | - | 0.1ohm | 1 Coil | 2 Layers | - | - | 3.81mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 3,990 € 10+ 3,640 € 25+ 2,960 € 50+ 2,750 € 100+ 2,620 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 8.23µH | ± 5% | 0.28ohm | 1 Coil | 1 Layer | 30mm | 30.4mm | 0.94mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 8,280 € 5+ 7,280 € 10+ 6,280 € 25+ 5,280 € 50+ 4,960 € Citas cenas... | Min.: 1 / Vair.: 1 | WR-NFC Series | 19.5µH | - | 0.8ohm | 1 Coil | 1 Layer | 52.5mm | 48.5mm | 0.62mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 9,450 € 5+ 8,270 € 10+ 6,850 € 25+ 6,140 € 50+ 5,670 € Citas cenas... | Min.: 1 / Vair.: 1 | WR-NFC Series | 16.8µH | - | 0.75ohm | 1 Coil | 1 Layer | 52.5mm | 48.5mm | 0.52mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 34,420 € 5+ 25,900 € 10+ 24,310 € 25+ 22,570 € 50+ 21,070 € | Min.: 1 / Vair.: 1 | WCT Series | 10.6µH | ± 0.5% | 0.149ohm | 1 Coil | 1 Layer | 67.01mm | 85.14mm | - | Board Mount | -40°C | 85°C | |||||
Each | 1+ 4,570 € 5+ 4,090 € 10+ 3,610 € 25+ 3,390 € 50+ 3,200 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 13.3µH | - | 0.2ohm | 1 Coil | 1 Layer | 32.5mm | 48.5mm | 1.25mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 3,760 € 10+ 3,140 € 50+ 2,460 € 100+ 2,250 € 200+ 2,070 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 11µH | ± 5% | 0.4ohm | 1 Coil | 2 Layers | - | - | 0.88mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 1,760 € 50+ 1,540 € 100+ 1,280 € 250+ 1,150 € 1000+ 1,060 € Citas cenas... | Min.: 1 / Vair.: 1 | WR Series | 27.9µH | ± 5% | 1.21ohm | 1 Coil | 2 Layers | 22mm | 12mm | 0.87mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 66,350 € 5+ 58,060 € 10+ 48,100 € 20+ 43,130 € 40+ 39,810 € | Min.: 1 / Vair.: 1 | WTM Series | 10µH | - | - | 1 Coil | 1 Layer | 52mm | 52mm | 4.34mm | Board Mount | -30°C | 70°C | |||||
Each | 1+ 18,600 € 5+ 17,830 € 10+ 17,060 € 25+ 16,970 € 50+ 16,870 € | Min.: 1 / Vair.: 1 | WRM Series | 8µH | - | - | 1 Coil | 1 Layer | 48.2mm | 32.7mm | 1.8mm | Board Mount | -30°C | 70°C | |||||
Pack of 384 | 384+ 10,880 € | Min.: 384 / Vair.: 384 | WT Series | 12.5µH | ± 10% | 0.09ohm | 3 Coils | 1 Layer | 101.8mm | 57.3mm | - | Board Mount | -30°C | 70°C | |||||
Pack of 320 | 320+ 3,830 € | Min.: 320 / Vair.: 320 | WT Series | 6.3µH | ± 10% | 0.06ohm | 1 Coil | 1 Layer | - | - | 2.69mm | Board Mount | -30°C | 70°C | |||||
