Transformer Cores:
Atrasti 844 produktiAtrodiet milzīgu Transformer Cores klāstu veikalā Farnell Latvija. Mēs piedāvājam plašu Transformer Cores izvēli, tostarp jaunus un populārākos produktus no pasaules labākajiem ražotājiem, tostarp: Epcos, Ferroxcube, Fair-rite & Laird.
Skatīt
Pircējs
Inženieris
Ražotājs
Core Type
Outer Diameter
Product Length
Core Size
Core Material Grade
Inner Diameter
For Use With
Effective Magnetic Path Length
Ae Effective Cross Section Area
Inductance Factor Al
Product Range
Iepakojums
Filtrs(-i) nav piemērots(-i)
0 Atlasīts(-ie) filtrs(-i)
| Salīdzināt | Cena par | Daudzums | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
3056028 RoHS | Each | 5+ 0,850 € 50+ 0,729 € 250+ 0,589 € 500+ 0,508 € 1000+ 0,469 € | Min.: 5 / Vair.: 5 | - | - | - | E18 | 3F4 | - | - | 20.3mm | 39.5mm² | 1.8µH | - | ||||
1 Pair | 1+ 2,350 € 50+ 1,270 € 100+ 1,110 € 250+ 1,100 € 500+ 1,080 € Citas cenas... | Min.: 1 / Vair.: 1 | RM | - | - | RM7 | N87 | - | - | 30.4mm | 43mm² | 2.7µH | B65819 Series | |||||
Each | 10+ 0,785 € 100+ 0,614 € 500+ 0,509 € 2500+ 0,400 € 4500+ 0,392 € Citas cenas... | Min.: 10 / Vair.: 10 | Planar E | - | - | E14 | 3F4 | - | - | 16.4mm | 14.2mm² | 100nH | - | |||||
1 Set | 1+ 45,400 € | Min.: 1 / Vair.: 1 | PM | - | - | PM87/70 | N27 | - | TDK B65713 Series Coil Formers | 146mm | 910mm² | 400nH | B65713 Series | |||||
1 Pair | 1+ 4,810 € 50+ 3,550 € 100+ 3,330 € 250+ 2,840 € 500+ 2,660 € Citas cenas... | Min.: 1 / Vair.: 1 | RM | - | - | RM6 | N48 | - | TDK B65807 Series Coil Formers | 26.9mm | 31.3mm² | 160nH | B65807 Series | |||||
1 Set | 1+ 3,870 € 50+ 2,850 € 100+ 2,680 € 250+ 2,290 € 500+ 2,130 € Citas cenas... | Min.: 1 / Vair.: 1 | RM | - | - | RM6 | N48 | - | High Q Inductors | 26.9mm | 31.3mm² | 250nH | B65807 Series | |||||
1 Set | 5+ 2,460 € 50+ 1,630 € 250+ 1,450 € 500+ 1,240 € 1000+ 1,160 € | Min.: 5 / Vair.: 5 | RM | - | - | RM6 | N48 | - | Transformers | 28.6mm | 36.6mm² | 160nH | B65807 Series | |||||
1 Set | 1+ 9,470 € 5+ 8,160 € 10+ 6,840 € 25+ 5,990 € 50+ 5,620 € Citas cenas... | Min.: 1 / Vair.: 1 | P | - | - | P26/16 | M33 | - | Inductors / Transformers | 37.2mm | 93mm² | 100nH | B65671 Series | |||||
Each | 1+ 3,850 € 10+ 3,070 € 50+ 2,560 € 100+ 2,220 € 200+ 2,050 € | Min.: 1 / Vair.: 1 | Toroid | - | - | 29.5mm x 19mm x 14.9mm | N30 | - | Inductors / Transformers | 73.78mm | 76.98mm² | 5.63µH | B64290L0647 Series | |||||
Each | 10+ 0,141 € 500+ 0,0576 € 2500+ 0,0475 € 10000+ 0,0415 € | Min.: 10 / Vair.: 10 | Multi-Aperture | - | - | 3.45mm x 2mm x 2.35mm | 61 | - | Baluns, Broadband Transformers, Airbags | - | - | 60nH | - | |||||
1 Set | 1+ 3,250 € 10+ 2,470 € 50+ 2,040 € 100+ 1,780 € 200+ 1,670 € Citas cenas... | Min.: 1 / Vair.: 1 | PM | - | - | P14/8 | N48 | - | TDK B65542 Series Coil Former | 20mm | 25mm² | 250nH | B65541 Series | |||||
Each | 10+ 0,236 € 500+ 0,158 € 2500+ 0,142 € | Min.: 10 / Vair.: 10 | Toroid | - | - | 5.84mm x 3mm x 1.65mm | 52 | - | Power Input Filters, Ground-Fault Interrupters, Common-Mode filters , Pulse & Broadband Transformers | 12.8mm | 2mm² | 49nH | - | |||||
Each | 10+ 0,732 € 100+ 0,540 € 500+ 0,457 € 1000+ 0,420 € 3000+ 0,364 € | Min.: 10 / Vair.: 10 | Toroid | - | - | 17mm x 10.7mm x 6.8mm | N30 | - | Transformers | 42mm | 21.04mm² | 2.71µH | B64290L0652 Series | |||||
Each | 1+ 1,430 € 10+ 1,160 € 50+ 0,949 € 100+ 0,828 € 200+ 0,788 € Citas cenas... | Min.: 1 / Vair.: 1 | E | - | - | E32/16/11 | N87 | - | Transformers | 74mm | 97mm² | 150nH | B66233 Series | |||||
Each | 1+ 6,230 € 5+ 5,220 € 10+ 4,210 € 25+ 3,550 € 50+ 3,460 € Citas cenas... | Min.: 1 / Vair.: 1 | Planar ELP | - | - | ELP43/10/28 | N49 | - | Transformers | 61.6mm | 225mm² | 5µH | B66291 Series | |||||
Each | 1+ 3,700 € 50+ 2,120 € 100+ 1,990 € 250+ 1,730 € 500+ 1,690 € | Min.: 1 / Vair.: 1 | Toroid | - | - | 25.3mm x 14.8mm x 20mm | N87 | - | Transformers | 60.07mm | 102.5mm² | 4.68µH | B64290L0616 Series | |||||
Each | 10+ 0,533 € 100+ 0,369 € 500+ 0,333 € 2500+ 0,267 € 3750+ 0,249 € Citas cenas... | Min.: 10 / Vair.: 10 | E | - | - | E5 | N87 | - | Miniature Transformers, DC/DC Converters | 12.6mm | 2.6mm² | 270nH | B66303 Series | |||||
Each | 1+ 2,810 € 5+ 2,490 € 10+ 2,160 € 25+ 1,590 € 50+ 1,510 € Citas cenas... | Min.: 1 / Vair.: 1 | ETD | - | - | ETD39/20/13 | N87 | - | SMPS Transformers | 92.2mm | 125mm² | 150nH | B66363 Series | |||||
1 Set | 5+ 3,120 € 50+ 2,290 € 250+ 2,020 € 500+ 1,720 € 1000+ 1,590 € | Min.: 5 / Vair.: 5 | RM | - | - | RM4 | N48 | - | Transformers | 21mm | 11mm² | 100nH | B65803 Series | |||||
1 Pair | 5+ 3,150 € 50+ 1,910 € 250+ 1,710 € 500+ 1,460 € 1000+ 1,360 € | Min.: 5 / Vair.: 5 | RM | - | - | RM5 | N49 | - | Transformers | 22.1mm | 23.8mm² | 1.3µH | B65805 Series | |||||
1 Pair | 5+ 2,760 € 50+ 1,590 € 250+ 1,410 € 500+ 1,210 € 1000+ 1,130 € | Min.: 5 / Vair.: 5 | RM | - | - | RM6 | N48 | - | Transformers | 26.9mm | 31.3mm² | 2.2µH | B65807 Series | |||||
Each | 5+ 1,600 € 50+ 0,813 € 250+ 0,812 € 500+ 0,811 € 1000+ 0,809 € Citas cenas... | Min.: 5 / Vair.: 5 | Toroid | - | - | 25.3mm x 14.8mm x 10mm | T65 | - | Inductors / Transformers | 60.07mm | 51.26mm² | 5.35µH | B64290L0618 Series | |||||
1 Pair | 1+ 7,250 € 10+ 5,670 € 50+ 4,700 € 100+ 4,320 € 200+ 4,000 € | Min.: 1 / Vair.: 1 | PQ | - | - | PQ26/25 | N49 | - | TDK B65878E Series Coil Former | 53.5mm | 122.2mm² | 3.3µH | B65877A Series | |||||
Each | 1+ 1,700 € 50+ 0,959 € 100+ 0,910 € 250+ 0,747 € 500+ 0,732 € | Min.: 1 / Vair.: 1 | EF | - | - | E32/16/9 | N87 | - | TDK B66230 Series Coil Former | 74mm | 83mm² | 145nH | B66229 Series | |||||
Each | 5+ 1,980 € 50+ 1,540 € 250+ 1,370 € 500+ 1,180 € 1000+ 1,090 € | Min.: 5 / Vair.: 5 | Planar EQ | - | - | EQ20/6.3/14 | N49 | - | Transformers | 33.2mm | 59mm² | 2.6µH | B66483 Series | |||||
