NPN and PNP Complement Pre-Biased / Digital Bipolar Transistors

Atrodiet milzīgu NPN and PNP Complement Pre-Biased / Digital Bipolar Transistors klāstu veikalā Farnell Latvija. Mūsu rīcībā ir plašs Pre-Biased / Digital Bipolar Transistors klāsts, piemēram, Single NPN, Single PNP, Dual NPN & NPN and PNP Complement Pre-Biased / Digital Bipolar Transistors no pasaules labākajiem ražotājiem, tostarp: Nexperia, Onsemi, Rohm, Diodes Inc. & Infineon.

Ražotājs

Transistor Polarity

Collector Emitter Voltage Max NPN

Collector Emitter Voltage Max PNP

Continuous Collector Current

Base Input Resistor R1

Base Emitter Resistor R2

Transistor Case Style

No. of Pins

Transistor Mounting

Power Dissipation

Operating Temperature Max

DC Current Gain hFE Min

Product Range

Qualification

Iepakojums

Piemērotais(-ie) filtrs(-i)

Transistor Polarity

NPN and PNP Complement

1 Atlasīts(-ie) filtrs(-i)

			Cena par		Daudzums

BCR35PNH6327XTSA1	2443495 Data Sheet RoHS Date/Lot Code	INFINEON Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 10 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,343 € 10+ 0,212 € 100+ 0,133 € 500+ 0,0911 € 1000+ 0,0797 € Citas cenas...	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	10kohm	47kohm	SOT-363	6 Pin	Surface Mount	250mW	150°C	70hFE	BCR35PN Series	AEC-Q101
BCR35PNH6327XTSA1	2443495RL Data Sheet RoHS Date/Lot Code	INFINEON Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 10 kohm	Each (Supplied on Cut Tape) Pārtīšana Iepakojuma iespējas	100+ 0,133 € 500+ 0,0911 € 1000+ 0,0797 € 5000+ 0,0684 €	Min.: 100 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	10kohm	47kohm	SOT-363	6 Pin	Surface Mount	250mW	150°C	70hFE	BCR35PN Series	AEC-Q101
DCX144EH-7	3944214 Data Sheet RoHS Date/Lot Code	DIODES INC. Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 47 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,334 € 10+ 0,221 € 100+ 0,143 € 500+ 0,0994 € 1000+ 0,0868 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	47kohm	47kohm	SOT-563	6 Pin	Surface Mount	150mW	150°C	68hFE	-	-
PIMC32-QX	3934774 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 500 mA 2.2 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,524 € 10+ 0,332 € 100+ 0,214 € 500+ 0,162 € 1000+ 0,142 € Citas cenas...	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	500mA	2.2kohm	10kohm	SOT-457	6 Pin	Surface Mount	420mW	150°C	70hFE	-	AEC-Q101
UMC4N-7	3944306 Data Sheet RoHS Date/Lot Code	DIODES INC. Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 47 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,638 € 10+ 0,395 € 100+ 0,256 € 500+ 0,178 € 1000+ 0,160 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	47kohm	47kohm	SOT-353	5 Pin	Surface Mount	150mW	150°C	68hFE	-	-
UMC4N-7	3944306RL Data Sheet RoHS Date/Lot Code	DIODES INC. Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 47 kohm	Each (Supplied on Cut Tape) Pārtīšana Iepakojuma iespējas	100+ 0,256 € 500+ 0,178 € 1000+ 0,160 €	Min.: 100 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	47kohm	47kohm	SOT-353	5 Pin	Surface Mount	150mW	150°C	68hFE	-	-
DCX144EH-7	3944214RL Data Sheet RoHS Date/Lot Code	DIODES INC. Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 47 kohm	Each (Supplied on Cut Tape) Pārtīšana Iepakojuma iespējas	500+ 0,0994 € 1000+ 0,0868 €	Min.: 500 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	47kohm	47kohm	SOT-563	6 Pin	Surface Mount	150mW	150°C	68hFE	-	-
PIMC32-QX	3934774RL Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 500 mA 2.2 kohm	Each (Supplied on Cut Tape) Pārtīšana Iepakojuma iespējas	100+ 0,214 € 500+ 0,162 € 1000+ 0,142 € 5000+ 0,106 €	Min.: 100 / Vair.: 5	NPN and PNP Complement	50V	50V	500mA	2.2kohm	10kohm	SOT-457	6 Pin	Surface Mount	420mW	150°C	70hFE	-	AEC-Q101
PUMD13,115	8738327 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 4.7 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,191 € 50+ 0,104 € 100+ 0,0753 € 500+ 0,0534 € 1500+ 0,0391 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	4.7kohm	47kohm	SOT-363	6 Pin	Surface Mount	200mW	150°C	100hFE	PUMD13 Series	-
MUN5311DW1T1G	2464148 Data Sheet RoHS Date/Lot Code	ONSEMI Bipolar Pre-Biased / Digital Transistor BRT NPN and PNP Complement 50 V 50 V 100 mA 10 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,238 € 10+ 0,130 € 100+ 0,0857 € 500+ 0,0595 € 1000+ 0,0517 € Citas cenas...	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	10kohm	10kohm	SOT-363	6 Pin	Surface Mount	385mW	150°C	35hFE	-	-
PUMD10,115	8738300 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor BRT NPN and PNP Complement 50 V 50 V 100 mA 2.2 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,229 € 50+ 0,136 € 100+ 0,0621 € 500+ 0,0583 € 1500+ 0,0544 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	2.2kohm	47kohm	SOT-363	6 Pin	Surface Mount	200mW	150°C	100hFE	PUMD10 Series	-
PUMD9,115	8738416 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor BRT NPN and PNP Complement 50 V 50 V 100 mA 10 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,210 € 50+ 0,117 € 100+ 0,0544 € 500+ 0,0501 € 1500+ 0,0458 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	10kohm	47kohm	SOT-363	6 Pin	Surface Mount	200mW	150°C	100hFE	PUMD9 Series	-
PUMD3,115	8738378 Data Sheet RoHS	NEXPERIA Bipolar Pre-Biased / Digital Transistor BRT NPN and PNP Complement 50 V 50 V 100 mA 10 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,195 € 50+ 0,131 € 100+ 0,0827 € 500+ 0,0546 € 1500+ 0,0399 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	10kohm	10kohm	SOT-363	6 Pin	Surface Mount	200mW	150°C	30hFE	PUMD3 Series	-
PUMD12,115	8738319 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor BRT NPN and PNP Complement 50 V 50 V 100 mA 47 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,210 € 50+ 0,126 € 100+ 0,0802 € 500+ 0,0544 € 1500+ 0,0458 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	47kohm	47kohm	SOT-363	6 Pin	Surface Mount	200mW	150°C	80hFE	PUMD12 Series	-
PUMD2,115	8738360 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 22 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,191 € 50+ 0,118 € 100+ 0,0734 € 500+ 0,0543 € 1500+ 0,040 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	22kohm	22kohm	SOT-363	6 Pin	Surface Mount	200mW	150°C	60hFE	PUMD2 Series	-
BCR10PNH6327XTSA1	2443488 Data Sheet RoHS Date/Lot Code	INFINEON Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 10 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,350 € 50+ 0,217 € 250+ 0,136 € 1000+ 0,0885 € 9000+ 0,0603 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	10kohm	10kohm	SOT-363	6 Pin	Surface Mount	250mW	150°C	30hFE	BCR10PN Series	AEC-Q101
PUMD48,115	8738394 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor BRT NPN and PNP Complement 50 V 50 V 100 mA 47 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,191 € 50+ 0,121 € 100+ 0,0773 € 500+ 0,0544 € 1500+ 0,0401 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	47kohm	47kohm	SOT-363	6 Pin	Surface Mount	200mW	150°C	80hFE	PUMD48 Series	-
PUMD15,115	8738335 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor BRT NPN and PNP Complement 50 V 50 V 100 mA 4.7 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,229 € 50+ 0,138 € 100+ 0,0858 € 500+ 0,0543 € 1500+ 0,0457 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	4.7kohm	4.7kohm	SOT-363	6 Pin	Surface Mount	200mW	150°C	30hFE	PUMD15 Series	-
PIMD3,115	2575108 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 10 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,315 € 10+ 0,192 € 100+ 0,120 € 500+ 0,0897 € 1000+ 0,0754 € Citas cenas...	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	10kohm	10kohm	SOT-457	6 Pin	Surface Mount	300mW	150°C	30hFE	-	AEC-Q101
PUMD2-QH	3912242 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 22 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,229 € 50+ 0,154 € 100+ 0,0868 € 500+ 0,0654 € 1500+ 0,0439 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	22kohm	22kohm	SOT-363	6 Pin	Surface Mount	300mW	150°C	60hFE	-	-
PUMD16,115	8738343 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 22 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,153 € 50+ 0,103 € 100+ 0,0525 € 500+ 0,0473 € 1500+ 0,042 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	22kohm	47kohm	SOT-363	6 Pin	Surface Mount	200mW	150°C	80hFE	PUMD16 Series	-
PUMD3,115	8738378RL Data Sheet RoHS	NEXPERIA Bipolar Pre-Biased / Digital Transistor BRT NPN and PNP Complement 50 V 50 V 100 mA 10 kohm	Each (Supplied on Cut Tape) Pārtīšana Iepakojuma iespējas	500+ 0,0546 € 1500+ 0,0399 €	Min.: 500 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	10kohm	10kohm	SOT-363	6 Pin	Surface Mount	200mW	150°C	30hFE	PUMD3 Series	-
UMD2NTR	1680394 Data Sheet RoHS Date/Lot Code	ROHM Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 22 kohm	Each	5+ 0,439 € 10+ 0,272 € 100+ 0,129 € 500+ 0,123 € 1000+ 0,116 € Citas cenas...	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	22kohm	22kohm	SOT-363	6 Pin	Surface Mount	150mW	150°C	56hFE	UMD2N Series	-
IMD2AT108	1680329 Data Sheet RoHS Date/Lot Code	ROHM Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 22 kohm	Each	5+ 0,419 € 10+ 0,296 € 100+ 0,193 € 500+ 0,146 € 1000+ 0,122 € Citas cenas...	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	22kohm	22kohm	SOT-457	6 Pin	Surface Mount	300mW	150°C	56hFE	IMD2A Series	-
PEMD30,115	2777615 Data Sheet RoHS Date/Lot Code	NEXPERIA Bipolar Pre-Biased / Digital Transistor NPN and PNP Complement 50 V 50 V 100 mA 2.2 kohm	Each (Supplied on Cut Tape) Griežama lente Iepakojuma iespējas	5+ 0,390 € 10+ 0,277 € 100+ 0,176 € 500+ 0,115 € 1000+ 0,0893 €	Min.: 5 / Vair.: 5	NPN and PNP Complement	50V	50V	100mA	2.2kohm	-	SOT-666	6 Pin	Surface Mount	300mW	150°C	30hFE	-	AEC-Q101
