Informācija par produktiem
RažotājsHONEYWELL
Ražotāja detaļas Nr.SDP8436-3
Pasūtījuma kods1201210
Tehnisko datu lapa
Wavelength Typ-
Viewing Angle18°
Power Consumption100mW
No. of Pins2Pins
Transistor Case StyleRadial Leaded
Product Range-
Automotive Qualification Standard-
Produktu pārskats
The SDP8436-3 is a Silicon NPN Phototransistor moulded in a black plastic package which combines the mounting advantages of a side-looking package with the narrow acceptance angle and high optical gain package. The SDP8436 is designed for those applications which require longer coupling distances than standard side-looking devices can provide, such as touch screens. The device is also well suited to applications in which adjacent channel crosstalk could be a problem. The package is highly transmissive to the IR source energy while it provides effective shielding against visible ambient light.
- 18° Acceptance angle (nominal)
- Enhanced coupling distance
- Internal visible light rejection filter
- Low profile for design flexibility
- Wide sensitivity ranges
- Mechanically matched to SEP8736 infrared emitting diodes
Lietošanas veidi
Sensing & Instrumentation
Tehniskie parametri
Wavelength Typ
-
Power Consumption
100mW
Transistor Case Style
Radial Leaded
Automotive Qualification Standard
-
Viewing Angle
18°
No. of Pins
2Pins
Product Range
-
Tehniskā dokumentācija (1)
Tiesību akti un vides aizsardzība
Izcelsmes valsts:
Valsts, kurā veikts pēdējais nozīmīgais ražošanas processIzcelsmes valsts:Great Britain
Valsts, kurā veikts pēdējais nozīmīgais ražošanas process
Valsts, kurā veikts pēdējais nozīmīgais ražošanas processIzcelsmes valsts:Great Britain
Valsts, kurā veikts pēdējais nozīmīgais ražošanas process
Tarifa Nr.:85414900
US ECCN:EAR99
EU ECCN:NLR
Atbilst RoHS:Jā
RoHS
Atbilst RoHS prasībām attiecībā uz ftalātiem:Jāiesaka
Lejupielādēt produkta atbilstības sertifikātu
Produkta atbilstības sertifikāts
Svars (kg):.01
