OHD3-40B
Thermostat Switch, Thermal Guard, OHD Series, Flange Mount, 40°C, Normally Closed, 110 VAC/DC, 300mA
Nepieciešams vairāk?
| Daudzums | |
|---|---|
| 1+ | 7,930 € |
| 10+ | 6,200 € |
| 25+ | 5,630 € |
| 50+ | 4,810 € |
| 100+ | 4,470 € |
Informācija par produktiem
Produktu pārskats
OHD3-40B is a OHD thermal guard developed for thermal problem counter which measures and safety standard conformity. Its unique proprietary design features a magnet and a temperature-sensing soft ferromagnetic substance called Thermorite®. The material’s magnetic flux density decreases as the temperature increases turning it into a paramagnetic substance at the Curie temperature. Typical applications include atmospheric temperature detection and overheating monitoring of power transistors, power modules, room heaters, hot gas heaters, PPCs, amplifiers, motors, HDDs, FDDs and other general appliances.
- Maximum opening/closing power of 6W
- High reliability for on/off operations
- High-speed response
- Long operational life
- Excellent environmental durability
- Extremely simple circuit design
- Operating temperature of 40°C
Tehniskie parametri
40°C
Break
Tab Leads
0.15ohm
110 VAC / VDC
300mA
CSA, TUV, UL
± 5°C
Radial Tab
OHD Series
6W AC / DC
100µA
10°C
No SVHC (21-Jan-2025)
Tehniskā dokumentācija (3)
Tiesību akti un vides aizsardzība
Valsts, kurā veikts pēdējais nozīmīgais ražošanas processIzcelsmes valsts:Japan
Valsts, kurā veikts pēdējais nozīmīgais ražošanas process
RoHS
RoHS
Produkta atbilstības sertifikāts
